Methanol

References

Equation of State

L. Piazza and R. Span. An equation of state for methanol including the association term of SAFT. Fluid Phase Equilib., 349:12–24, 2013. doi:10.1016/j.fluid.2013.03.024.

Thermal Conductivity

E. A. Sykioti, M. J. Assael, M. L. Huber, and R. A. Perkins. Reference Correlation of the Thermal Conductivity of Methanol from the Triple Point to 660 K and up to 245 MPa. J. Phys. Chem. Ref. Data, 42:043101, 2013. doi:10.1063/1.4829449.

Viscosity

Hong Wei Xiang, Arno Laesecke, and Marcia L. Huber. A New Reference Correlation for the Viscosity of Methanol. J. Phys. Chem. Ref. Data, 35(4):1597–1:24, 2006. doi:10.1063/1.2360605.

Melting Line

K.M. de Reuck and R.J.B. Craven. Methanol: International Thermodynamic Tables of the Fluid State - 12. Blackwell Scientific Publications, 1993.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

methanol, METHANOL

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.03204216

CAS number

67-56-1

ASHRAE class

UNKNOWN

Formula

\(CH_{4}O\)

Acentric factor

0.5720322

InChI

InChI=1S/CH4O/c1-2/h2H,1H3

InChIKey

OKKJLVBELUTLKV-UHFFFAOYSA-N

SMILES

CO

ChemSpider ID

864

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=864

Limits

Maximum temperature [K]

620.0

Maximum pressure [Pa]

500000000.0

Triple point

Triple point temperature [K]

175.61

Triple point pressure [Pa]

0.18676381241403228

Critical point

Critical point temperature [K]

512.5

Critical point density [kg/m3]

273.0

Critical point density [mol/m3]

8520.024867237415

Critical point pressure [Pa]

8215850.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Methanol.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Methanol1.png
