Cyclopentane

References

Equation of State

Holger Gedanitz, María J. Dávila, and Eric W. Lemmon. Speed of sound measurements and a fundamental equation of state for cyclopentane. J. Chem. Eng. Data, 60(5):1331–1337, 2015. doi:10.1021/je5010164.

Thermal Conductivity

C-M Vassiliou, MJ Assael, ML Huber, and RA Perkins. Reference Correlations of the Thermal Conductivity of Cyclopentane, iso-Pentane, and n-Pentane. Journal of Physical and Chemical Reference Data, 44(3):033102, 2015.

Viscosity

Ting Horng Chung, Mohammad Ajlan, Lloyd L Lee, and Kenneth E Starling. Generalized multiparameter correlation for nonpolar and polar fluid transport properties. Ind. Eng. Chem. Res., 27(4):671–679, 1988. doi:10.1021/ie00076a024.

Surface Tension

A. Mulero and I. Cachadiña. Recommended Correlations for the Surface Tension of Several Fluids Included in the REFPROP Program. J. Phys. Chem. Ref. Data, 43:023104–1:8, 2014. doi:10.1063/1.4878755.

Aliases

CycloPentane, cyclopentane, CYCLOPENTANE, CYCLOPEN

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.07013290000000001

CAS number

287-92-3

ASHRAE class

UNKNOWN

Formula

\(C_{5}H_{10}\)

Acentric factor

0.201112573380599

InChI

InChI=1S/C5H10/c1-2-4-5-3-1/h1-5H2

InChIKey

RGSFGYAAUTVSQA-UHFFFAOYSA-N

SMILES

C1CCCC1

ChemSpider ID

8896

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=8896

Limits

Maximum temperature [K]

550.0

Maximum pressure [Pa]

250000000.0

Triple point

Triple point temperature [K]

179.70000000000002

Triple point pressure [Pa]

8.854271413109606

Critical point

Critical point temperature [K]

511.72

Critical point density [kg/m3]

267.9076780000001

Critical point density [mol/m3]

3820.000000000001

Critical point pressure [Pa]

4571200.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Cyclopentane.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Cyclopentane1.png
