R1243zf

References

Equation of State

Ryo Akasaka and Eric Lemmon. New Fundamental Equations of State for cis-1,3,3,3-Tetrafluoropropene [R-1234ze(Z)] and 3,3,3-Trifluoropropene (R-1243zf). J. Chem. Eng. Data, 2019, submitted.

Aliases

R1243ZF

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.09605113

CAS number

677-21-4

ASHRAE class

?

Formula

\(C_{3}F_{3}H_{3}\)

Acentric factor

0.2603679382574058

InChI

InChI=1S/C3H3F3/c1-2-3(4,5)6/h2H,1H2

InChIKey

FDMFUZHCIRHGRG-UHFFFAOYSA-N

SMILES

C=CC(F)(F)F

ChemSpider ID

12151

2D image

 http://www.chemspider.com/ImagesHandler.ashx?id=12151

Limits

Maximum temperature [K]

410.0

Maximum pressure [Pa]

30000000.0

Triple point

Triple point temperature [K]

220.0

Triple point pressure [Pa]

25832.072524917538

Critical point

Critical point temperature [K]

376.93

Critical point density [kg/m3]

413.019859

Critical point density [mol/m3]

4300.0

Critical point pressure [Pa]

3517867.1261784267

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R1243zf.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R1243zf1.png
