DiethylEther

References

Equation of State

Monika Thol, Lorenzo Piazza, and Roland Span. A New Functional Form for Equations of State for Some Weakly Associating Fluids. Int. J. Thermophys., 35(5):783–811, 2014. URL: http://dx.doi.org/10.1007/s10765-014-1633-1, doi:10.1007/s10765-014-1633-1.

Surface Tension

A. Mulero and I. Cachadiña. Recommended Correlations for the Surface Tension of Several Fluids Included in the REFPROP Program. J. Phys. Chem. Ref. Data, 43:023104–1:8, 2014. doi:10.1063/1.4878755.

Aliases

DEE, DiethylEther

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.0741216

CAS number

60-29-7

ASHRAE class

UNKNOWN

Formula

\(C_{4}H_{10}O\)

Acentric factor

0.2819293311752744

InChI

InChI=1S/C4H10O/c1-3-5-4-2/h3-4H2,1-2H3

InChIKey

RTZKZFJDLAIYFH-UHFFFAOYSA-N

SMILES

CCOCC

ChemSpider ID

3168

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=3168

Limits

Maximum temperature [K]

548.0

Maximum pressure [Pa]

100000000.0

Triple point

Triple point temperature [K]

270.0

Triple point pressure [Pa]

21283.811029807

Critical point

Critical point temperature [K]

466.7

Critical point density [kg/m3]

263.99999971968

Critical point density [mol/m3]

3561.7148

Critical point pressure [Pa]

3649016.896528536

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DiethylEther.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DiethylEther1.png
