DimethylEther

References

Equation of State

Jiangtao Wu, Yong Zhou, and Eric W. Lemmon. An Equation of State for the Thermodynamic Properties of Dimethyl Ether. J. Phys. Chem. Ref. Data, 40(2):023104–1:16, 2011. doi:10.1063/1.3582533.

Viscosity

Xianyang Meng, Jianbo Zhang, Jiangtao Wu, and Zhigang Liu. Experimental Measurement and Modeling of the Viscosity of Dimethyl Ether. J. Chem. Eng. Data, 57:988–993, 2012. doi:10.1021/je201297j.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

DIMETHYLETHER, DME

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.04606844

CAS number

115-10-6

ASHRAE class

A3

Formula

\(C_{2}H_{6}O\)

Acentric factor

0.196

InChI

InChI=1S/C2H6O/c1-3-2/h1-2H3

InChIKey

LCGLNKUTAGEVQW-UHFFFAOYSA-N

SMILES

COC

ChemSpider ID

7956

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=7956

Limits

Maximum temperature [K]

525.0

Maximum pressure [Pa]

50000000.0

Triple point

Triple point temperature [K]

131.66

Triple point pressure [Pa]

2.210728491107207

Critical point

Critical point temperature [K]

400.378

Critical point density [kg/m3]

273.64653360000005

Critical point density [mol/m3]

5940.000000000001

Critical point pressure [Pa]

5336800.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DimethylEther.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DimethylEther1.png
