p-Xylene

References

Equation of State

Yong Zhou, Jiangtao Wu, and Eric W. Lemmon. Thermodynamic Properties of o-Xylene, m-Xylene, p-Xylene, and Ethylbenzene. J. Phys. Chem. Ref. Data, 41(2):023103–1 – 023103–26, 2012. doi:10.1063/1.3703506.

Thermal Conductivity

S. K. Mylona, K. D. Antoniadis, M. J. Assael, M. L. Huber, and R. A. Perkins. Reference Correlations of the Thermal Conductivity of o-Xylene, m-Xylene, p-Xylene, and Ethylbenzene from the Triple Point to 700 K and Moderate Pressures. J. Phys. Chem. Ref. Data, 43:043104, 2014. doi:10.1063/1.4901166.

Viscosity

B. Balogun, N. Riesco, and V. Vesovic. Reference Correlation of the Viscosity of para-Xylene from the Triple Point to 673 K and up to 110 MPa. J. Phys. Chem. Ref. Data, 44:013103, 2015. doi:10.1063/1.4908048.

Surface Tension

A. Mulero and I. Cachadiña. Recommended Correlations for the Surface Tension of Several Fluids Included in the REFPROP Program. J. Phys. Chem. Ref. Data, 43:023104–1:8, 2014. doi:10.1063/1.4878755.

Aliases

pXylene, p-xylene, P-XYLENE, PC8H10

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.106165

CAS number

106-42-3

ASHRAE class

Formula

\(C_{8}H_{10}\)

Acentric factor

0.324

InChI

InChI=1S/C8H10/c1-7-3-5-8(2)6-4-7/h3-6H,1-2H3

InChIKey

URLKBWYHVLBVBO-UHFFFAOYSA-N

SMILES

Cc1ccc(cc1)C

ChemSpider ID

7521

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=7521

Limits

Maximum temperature [K]

700.0

Maximum pressure [Pa]

200000000.0

Triple point

Triple point temperature [K]

286.40000000000003

Triple point pressure [Pa]

580.08500237559

Critical point

Critical point temperature [K]

616.168

Critical point density [kg/m3]

286.00001679999997

Critical point density [mol/m3]

2693.92

Critical point pressure [Pa]

3531500.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/p-Xylene.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/p-Xylene1.png
